| Function | Parameter |
| WorkingFrequencyRange | 433MHzISM frequency range |
| Communication Distance | Up to 300m at open places. |
| Light Source Type | 650nm graphic laser diode |
| Use Mode | Hand-held |
| Bit error rate | 1/3 million |
| Safety Performance | Meet the Grade II National Criteria for Laser Safety |
| Barcode Type | UPC-A,UPC-E,Industrial 2 of 5,EAN8,EAN13,Code 128,EAN128,Code39,Code93,Codabar 12 etc all 1D code. |
| Supported Interface | USB |
| Scanning Mode | Manual |
| Transmission Rate | RS232 Baudrate: 2400-38400 |
| Resolution (pcs0.9) | 0.10mm(4mil) |
| Depth of Field | 10-800mm (pos0.9) |
| Reading Speed | 100 times/second |
| Reading angleof elevation | 60 |
| Reading angle of dip | 45 |
| Operating temperature | -20 -45 |
| Storage temperature | -20 -45 |
| Operating humidity | 5%-85% |
| Storage humidity | 5%-85% |
| Power supply | 5V |
| Working current | 120mA |
| Static current | 30mA |
| Fall test | 100times/1.5m |
| Light intensity | Daylight 4000lux max |
| EMC | CE&FCC DOC compliance |
| lase class | meet the Grade II National Criteria for laser safety |
| shock | designed to withstand 1.5M drops |
| Exterior dimension | L x W x H: 166mm x 66mm x 86mm |
| Materials | ABS+pc |
| Weight | 218g |
