Solar Charge Controller MPPT 40A 30A 20A Blacklight LCD Solar Regulator 12V 24V Auto Tracer1210AN 2210AN 3210AN 4210AN

The Tracer AN series. Based on common negative design and advanced MPPT control algorithm, with LCD displaying running status, this product is artistic, economical and practical
Item No. COBD211040 Price Down Notice
In Stock
Price:
US$76.42/ piece
Discount Price:
US$45.00/ piece 41%
Color:
Quantity:

Shipping:
Express Shipping Service
Estimated delivery time: 3-15 working days.See details »
Returns:
Return for refund within 7 days,buyer pays return shipping.Read details »
Support:
Online Chat WhatsApp Skype Ask a question
Solar Charge Controller 10A 20A 30A 40A Blacklight LCD Solar Regulator 12V 24V Auto Tracer1210AN 2210AN 3210AN 4210AN TOP

Overview:

The Tracer AN series. Based on common negative design and advanced MPPT control algorithm, with LCD displaying running status, this product is artistic, economical and practical. Improving the MPPT control algorithm further, Tracer AN series can minimize the maximum power point loss rate and loss time, quickly track the maximum power point of the PV array and obtain the maximum energy from solar modules under any conditions; and can increase the ratio of energy utilization in the solar system by 10%-30% compared with a PWM charging method. The limitation function of the charging power and current and reducingcharging power function automatic improve the stability which works even connecting oversize PV modules and in high temperature, and increase the professional protection chip for the communication port, further improving the reliability and meeting the different application requirements.

Features:

  • Advanced MPPT technology, with efficiency no less than 99.5%\Ultra-fast tracking speed and guaranteed tracking efficiency

  • Advanced MPPT control algorithm to minimize the maximum power point loss rate and loss time

  • Wide MPP operating voltage range

  • High quality components, perfecting system performance, with maximum conversion efficiency of 98%

  • Accurate recognition and tracking of multiple-peaks maximum power point

  • International famous brands of ST and IR's components of high quality and low failure rate are used, which can ensure the product’s service life

  • Charging power and current limitation function

  • Compatible with lead-acid and lithium-ion batteries

  • Battery temperature compensation function

  • Real-time energy statistics function

  • Overheating power reduction function

  • Multiple load work modes

  • The communication port adopts professional protection chip, which can provide 5VDC power supply, and has over-current and short-circuit protection.

  • With RS-485 communication bus interface and Modbus communication protocol, it is available to meet various communication requirements in different situations.

  • Monitor and set the parameters via mobile phone APP or PC software

  • Full-load operation without any drop in capacity within the range of working environment temperature

  • Extensive electronic protection

Note:

There are accessory links and collocations at the bottom,

which can be combined and matched freely

Technical Specifications:

Item

Tracer 1206AN

Tracer 2206AN

Tracer 1210AN

Tracer 2210AN

Tracer 3210AN

Tracer 4210AN

System nominal voltage

12V/24VDC Auto

Rated charge current

10A

20A

10A

20A

30A

40A

Rated discharge current

10A

20A

10A

20A

30A

40A

Battery voltage range

8~32V

Max. PV open circuit voltage

46V

92V

MPP voltage range

(Battery voltage +2V)~36V

(Battery voltage +2V)~72V

Max. PV input power

130W/12V
260W/24V

260W/12V
520W/24V

130W/12V
260W/24V

260W/12V
520W/24V

390W/12V
780W/24V

520W/12V
1040W/24V

Self-consumption

<=12mA

Discharge circuit voltage drop

<=0.23V

Temperature compensate coefficient

-3mV/°C/2V (Default)

Grounding

Common negative

RS485 interface

5VDC/100mA

LCD backlight time

60S (Default)

Environmental Parameters

Working environment temperature

-25°C~+50°C(100% input and output)

Storage temperature range

-20°C~+70°C

Relative humidity

<=95%, N.C.

Enclosure

IP30

Dimension

172x139 x 44mm

220x154x 52mm

172x139 x 44mm

220x154x 52mm

228x164x55mm

252x180x63mm

Mounting dimension

130x130mm

170x145mm

130x130mm

170x145mm

170x164mm

210x171mm

Terminal

12AWG(4mm 2 )

6AWG(16mm 2 )

12AWG(4mm 2 )

6AWG(16mm 2 )

6AWG(16mm 2 )

6AWG(16mm 2

Recommended cable

12AWG(4mm 2 )

10AWG(6mm 2 )

12AWG(4mm 2 )

10AWG(6mm 2 )

8AWG(10mm 2 )

6AWG(16mm 2 )

Weight

0.57kg

0.94kg

0.57kg

0.94kg

1.26kg

1.65kg

SET

SET

Set

2210AN-Set

3210AN-Set


Photo:
